Combined Sensor Light and Presence detection

DPWA*
CAREL Sensors for measuring ambient light and occupancy
  • General characteristics

    Sensors for measuring ambient light and occupancy, to be used in combination with CAREL or third-party electronic controllers. These sensors contribute to ensuring intelligent management of electrical loads, rationalising power consumption and consequently saving energy.



    The combined light and presence detection sensor DPWA series for indoor and outdoor installation are instrument that detects motions and light intensity as well as the presence of persons and is used to recognize environment conditions.

    The output signal is 4...20 mA for light intensity and has a switching (changeover contact SPDT) output for the detection of motions. Those combined sensors are installed, where is necessary use a device for the observation and recognition of

    conditions and for a motion dependent control of room functions, e.g. as motion detector to lower temperatures in unused

    rooms.



Documentation

Technical

  • Quick Guide
    Code Description Language Date Release
    Code +040010025.pdf

    Description Sonde e sensori / Probes and sensors Guida alla scelta e all'installazione ottimale Selection and optimal installation guide

    Language ENG  ITA

    Date 12/11/2015

    Release 1.0

    Code +040010026

    Description 'Sondes et capteurs / Fühler und Sensoren Guide pour le choix et l'installation optimale Auswahl- und Installationshilfe

    Language FRE  GER

    Date 12/11/2015

    Release 1.0

    Code +040000045

    Description Installazione sensori Luce e Presenza Installation Light and Presence detection Sensor

    Language ENG  ITA

    Date 21/10/2014

    Release 1.0

  • Technical Leaflets
    Code Description Language Date Release
    Code +0500078ML

    Description Sensore combinato di luce e presenza - Versione interna ed esterna / Combined Sensor - Light and Presence detection – indoor and outdoor version / Capteurs combiné de présence et lumière - version d’intérieur et d’extérieur / Kombinierter Licht- und Bewegungssensor - Innen- und Außenversion / Sensor combinado de luz y presencia - Versión interna y externa

    Language ENG  FRE  GER  ITA  SPA

    Date 24/09/2014

    Release 1.0
